19'' Standard Rack Cabinet, 19 Inch Network Cabinet, Glass Door Application
These network racks, specially designed for equipment rooms and administration rooms, can house power supply and cooling systems, and install heavy equipment. The wall-mounted racks are mainly used in CP distribution in small server rooms or large public places, as well as distribution rooms whose coverage is limited by the size of smart buildings. The TC wall-mounted racks are designed for network application, making it possible to securely install and organize network equipment, patch panels, and other EIA-compliant 19" equipment.
Product Features
The racks have tempered glass front doors and cold-rolled perforated front doors (optional), single front/rear doors, and field-detachable side/rear doors which speed up field installation and future maintenance. Meanwhile, all doors can be locked to provide strong support for the inside device and information transmission.
The racks boast a high-strength cold-rolled steel structure, reasonable and solid, with electrostatic powder sprayed on the surface, effectively avoiding bumps and corrosion. Cooling fans and adjustable equipment trays are all pre-installed. The perforated design in the front door provides cooling for active equipment. Available with 5mm tempered glass or perforated front door, huge in interior space, elegant in outer appearance, exquisite in craft, and precise in size.
This product complies with GB/T 3047.2-92, ANSI/EIA RS-310-D, and DIN41491. It also provides a fast detachable structure and reasonable cable routing.
Application Standards
GB/T 18233 (ISO/IEC 11801); GB 50311; GB50174; TIA/EIA568.2-D
Specifications
|
Protection Rating |
IP20 |
|
Main Material |
SPCC high-quality high strength cold rolled steel |
|
Thickness |
IT Racks: Square frame: 2.0mm, Beam: 1.5mm, Front/Rear/Top/Bottom Cover: 1.2mm, Others ≥ 1.0mm |
|
Mounting Rails |
In accordance with GB3047.2, IEC297-2, DIN41491 PART1, DIN41494 PART7, ANSI/EIARS-310-D; Compatible with ETSI |
|
Model |
Description |
Size |
Color |
|
AB-11-66-42 |
42U Rack, 3*Partition, 2*Fan, 1*6-port 10A Power Strip, 90*Screw, Front Glass and Rear Iron Door |
2050×600×600 |
Black RAL9005 |
|
AB-11-66-37 |
37U Rack, 2*Partition, 2*Fan, 1*6-port 10A Power Strip, 80*Screw, Front Glass and Rear Iron Door |
1830×600×600 |
Black RAL9005 |
|
AB-11-66-32 |
32U Rack, 2*Partition, 2*Fan, 1*6-port 10A Power Strip, 70*Screw, Front Glass and Rear Iron Door |
1607×600×600 |
Black RAL9005 |
|
AB-11-66-27 |
27U Rack, 1*Partition, 2*Fan, 1*6-port 10A Power Strip, 50*Screw, Front Glass and Rear Iron Door |
1385×600×600 |
Black RAL9005 |
|
AB-11-66-22 |
22U Rack, 1*Partition, 2*Fan, 1*6-port 10A Power Strip, 40*Screw, Front Glass and Rear Iron Door |
1165×600×600 |
Black RAL9005 |
|
AB-11-66-18 |
18U Rack, 1*Partition, 2*Fan, 1*6-port 10A Power Strip, 30*Screw, Front Glass and Rear Iron Door |
945×600×600 |
Black RAL9005 |
|
AB-11-68-42 |
42U Rack, 3*Partition, 4*Fan 机 , 1*6-port 10A Power Strip, 90*Screw, Front Glass and Rear Iron Door |
2050×600×800 |
Black RAL9005 |
|
AB-11-610-42 |
42U Rack, 3*Partition, 4*Fan, 1*6-port 10A Power Strip, 90*Screw, Front Glass and Rear Iron Door |
2050×600×1070 |
Black RAL9005 |
|
AB-11-88-42 |
42U Rack, 3*Partition, 4*Fan, 1*6-port 10A Power Strip, 2*Vertical Cable Manager, 90*Screw, Front Glass and Rear Iron Door |
2050×800×800 |
Black RAL9005 |
